DIECI 4X6" 2-WAY COAXIAL SPEAKER - PAIR (DCX 460.3)

Description

The Hertz DCX 460.3 (Order Code DCX460.3) car audio coaxial features a neodymium magnet, PEI dome tweeter, built-in crossover, TPU (Thermoplastic polyurethane) surround and a copper mobile voice coil wound on conex former. This 2-way coax speaker is designed to satisfy specific installation and listening needs. An extremely light, yet stiff structure ensures linear frequency response and a high sensitivity level.

Specifications

• System: Coaxial
• Size: 4x6"
• Power Handling:
  • Continuous: 40W
  • Peak: 80W
• Impedance: 4 Ohm
• Tweeter Diaphragm:
• Woofer Voice Coil: 25mm (1")
• Tweeter Voice Coil:
• Frequency Response: 65 - 21k Hz
• Sensitivity: 93 dB
• Woofer Magnet Size (D x d x h): 80 x 32 x 10mm
• Tweeter Magnet Size (D x h):
• Weight of One Woofer: 0.58 kg
• Woofer Magnet: High Density Flux Ferrite
• Tweeter Magnet: Neodymium
• Cone: Water-Repellent Pressed Paper
• Dome: PEI

Features

• Large motor assembly for mobile voice coil control.
• Pure copper voice coil, wound on conex former, for maximum lightness.
• Water-repellent treated paper cone.
• TPU surround, for wide excursion and resonance damping.
• Neodymium tweeter with PEI dome, for compactness and energy at high frequencies.
• DIN size basket protected by abrasion-proof dust paint.
• Tin-plated, high current terminals.
• Silver-plated lead wires for maximum reliability and conductivity.
• Epoxy glue for basket and motor system provides perfect coupling.
• Low carbon content plates for maximum magnetic permeability and high heat dissipation

Packaging

Giftbox
